Optiona List
The warranty for TSL-210 is one year. We recommend to have TSL-210 inspected and
calibrated regularly ( once a year recommended).
*1: Output power decreases 20% with optical lter.
*2: Face of ferrule: SS-CS-001A FH(Protrusion): -100~100nm / ROC(Spherical radius): 5~12mm / AA(Polish angle): 7.7~8.3_/ AO(Elleptical
center): ≤50µm / Key error: -0.5~0.5º
parameter Unit Min. Spec. Max. Note
Wavelength
Tuning range nm 1260 - 1640 Maximum tuning range: >80nm (choose from 1260~1640nm)
Power
Maximum output power mW 10 - - High power output
Built in attenuator dB 0 - 20 Resolution 0.04dB(Typ.)
Built in tracking lter nm - - - -3dB bandwidth: 3nm, Resolution 0.24nm(Typ.)*1
Interface
Optical connector - - SC -
Optical ber - - PMF -
SLOW axis, Polarization extinction ratio>17dB,Polarization
angle error<10
o
Connector polish - - APC - Angled polish connector*2
RF Modulation
Modulation range MHz 1 - 100 Measured at -3dB
input level dBm - - 0
Input impedance
Ω
- 50 -
Modulation input - - SMA - Input from the rear panel
