TUNABLE LD LIGHT SOURCE TSL-210
6-1
6
Installation
Pay attention to the following guidelines for safe, trouble-free operation.
This product is a high-precision device:
• Do not place in direct sunlight
• Do not place under high temperature and high humidity.
• Do not place in an environment with dust, dirt, salt, or corrosive gas.
• Do not place in an area subject to large vibrations.
• Do not place in an area subject to noise by electric field, magnetic field, etc.
• Do not place in an area where the unit is subject to falling objects landing on it.
• Do not place with possible exposure to water
Install the TSL-210 in a level place. It is recommended to install this product on a vibration-proof
base. The mainframe of the TSL-210 weighs about 7 kg. Please ensure that the table or shelf
upon which it is installed has sufficient strength. Clearance of 5 cm at the rear side of the unit
should be allowed for proper ventilation.
• Before connecting the power cord
Set the power voltage.
Open the lid of power input portion of the rear panel, and switch the power voltage to your
desired voltage by turning the rotary switch.
(Refer to 7.Descriptions of Panel Equipment)
• Power fuse
It is necessary to exchange fuses in accordance with power voltage.
(Refer to 7.Descriptions of Panel Equipment)
In the case of power voltage AC100V/120V T3A/125V
In the case of power voltage AC230V/240V T1.6A/250V
* Use a surge resistant type fuse.
• Power cord connection
This product uses a 3-line power cord and plug with a protective ground line. Power cord
may be attached and detached, Connect it to the power source socket at the rear panel.
Use the power cord supplied with the unit.
Do not remove the rubber feet from the device as they are used to maintain a heat
releasing vent.
This product is grounded by the ground line of the power cord.
Insufficient grounding may cause electric shock, which is very dangerous.
To avoid electric shock, be sure the unit is properly grounded.
CAUTION
NOTE
