7-2 Rear Panel
(1) GP-IB connector (Refer to 10-5 GP-IB)
(2) AIF (analog interface) connector
Terminal for ne tuning control and low frequency modulation from external.
(3) Option Panel
Input terminal for level adjustment knob of variable coherence control and RF modulation of
options.
(4) Power voltage display panel
This changes when the inside rotary switch is changed. This displays the power voltage that
can be supplied at present. If a different power voltage is used, make sure the rotary switch is
set properly and the correct fuse is used.
