TUNABLE LD LIGHT SOURCE TSL-210
3-1
Specications
3
Specication
parameter Unit Min. Spec. Max. Note
Wavelength
Tuning range nm 1530 - 1610
Minimum tuning nm 80 - -
Resolution nm - - 0.01 <0.001nm When using ne tuning
Accuracy nm - - 0.1
Repeatability nm - - 0.05
Number of times of measurement n=50, Measured at center
wavelength
Stability nm - - 0.01 1 hour, Measured at center wavelength
Fine tuning range GHz 10 - - 0.08nm(Typ.)
Tuning speed ms/nm 170 - -
Power
Maximum output power mW
8 - -
6 - - Minimum output power between a certain 40nm
4 - - Minimum output power
Accuracy % - - 5
Repeatability dB - - 0.01
Number of times of measurement n=50, Measured at center
wavelength, +6dBm
Stability dB - - 0.01 1 hour, Measured at center wavelength, +6dBm
Flatness dB - - 0.2 Measured at +6dBm
Environmental condition
Operating temp. range
o
C 20 - 30
Operating humidity range % - - 80 No condensation
Storage temp. range
o
C 10 - 40
Storage humidity range % - - 80 No condensation
Recalibration period Year 1 - - Recommended
Spectrum
Spectrum line width MHz
- - 1 Coherence control OFF
1 - 500 Coherence control ON
SSR dB 45 - - 50dB(Typ.)
Interface
Optical connector - - FC -
Optical ber - - SMF - SM, 10/125-UV/UV-250
Connector polish - - SPC - Supoer polish connector
GP-IB - - Yes - IEEE-488
RS-232IF - - Yes - Input from SIF interface on the front panel
LF Modulation
Modulation range KHz 0 - 10 Measured at -3dBm
Input level V -1 - 1
Modulation coefcient mA/V - 100 -
Input impedance KΩ - 4.7 -
Modulation input - - AIF - Input from the rear panel
Power supply
Voltage V AC100/120/230/240
Frequency Hz 50/60
Power consumption VA AC100/120:35 AC230/240:55
Max. power consumption W 80 40W(Typ.)
Laser safety class - 3A
Dimensions
Width, Height, Depth mm 210,110,370 Excludes the projection
Weight kg 6
