10-1-C GP-IB Function
GP-IB has 10 kinds of interface functions, each of which has its grade that is called it's sub
set. A "O" after the symbol of each function shows that support is not made, and each numeric
value represents grade.
Symbol Function TSL-210 Sub Set
SH Source SH:1 all functions
AH Acceptor handshake AH:1 all functions
T Talker T8: basic talker, listener release by MLA
L Listener L4: basic listener, talker release by MTA
TE Expanded talker TEO: none
LE Expanded listener LEO: none
SR Service request SRO: none
RL Remote/local RL1: switching of remote/local, local lockout
PP Parallel port PPO: none
DT Device trigger DTO: none
DC Device cleaner DC1: all functions
C Controller CO: none
10-1-D GP-IB of TSL-210
1. Address
When the system is turned on, the address is displayed. To conrm or change an address, press
the SHIFT key at the front panel, and then press the LOCAL key; the optical output power dis-
play will change into the GP-IB address display, which can be changed by the rotary encoder.
Press LOCAL after making the change, and the GP-IB address will be stored into TSL-210
EEROM (electrically erasable and programmable read only memory).(Refer to 9-10. Setting
GP-IB Address)
2. Remote/Local Function
Remote status occurs when the TSL-210 conrms MLA (My Listener Address) or MTA (My
Talker Address) irrespective of true or false of REN (remote enable) of control lines. In remote
status, other operation than local key from the front panel cannot be accepted. To return from
remote status to local status, press LOCAL key at the front panel or execute the GP-IB com-
mand GTL (Go To Local). In the TSL-210, GTL is valid only when REN is true. And even
if REN changes from true to false, it will not return to local status. Further, after execution of
LLO (Local Lock Out), local key even from the front panel cannot be accepted, and it cannot
return to local status even by GTL. To release LLO, execute IFC
(Inter Face Clear) irrespective of true or false of REN.
3. Device Clear Function
When DCL (Device Clear) is executed, TSL-210 is reset.
