Santec TSL-210 - 13-2 Control Pad (CP-10)

13-2
TSL-210 OPERATION MANUAL
13-2 Control Pad (CP-10)
Rear Panel Layout
• High Frequency Modulation Input Terminal (SMA)
TSL-210 is designed with a simple and easy to use front panel interface. It has minimal func-
tion keys and does not have a numeric keypad for direct wavelength and power setting input.
The CP-10 control pad addresses both of these issues, and provides full support of all functions
in a compact, handheld design. The unit is programmable enabling up to 128 combinations of
wavelength and power settings to be stored and wavelegnth sweeps to be performed.
The CP-10 unit connects to the TSL-210 unit through the front panel SIF connector and com-
municates through the RS-232C interface.
ENT
BS
F
1
F
2
F
3
F
4
F
5
AT
T
COH
ACC
LD
TEMP
LIMIT BUS
Y
7
8 9
4 5
6
1 2 3
.
0
–

CONTROL PAD CP-10
santec
