-66-
Electrical Adjustment
Group/
Item
Item Name Function Initial Range Note
Group 47 Noise Reduction (Time) Effective only for N.R L1
0 Noise Pixel Range <NSRANGEY> / <NSRANGEUV> 1 0 - 2
1 Noise Region 0 <NSREGIONY0> / <NSREGIONUV0> 12 0 - 1023
2 Noise Region 1 <NSREGIONY1> / <NSREGIONUV1> 24 0 - 1023
3 Noise Region 2 <NSREGIONY2> / <NSREGIONUV2> 40 0 - 1023
4 Noise Gain Level <NSFILTERY**> / <NSFILTERUV**> 50 0 - 255
Group 49 Noise Reduction (Time) Effective only for N.R L2
0 Noise Pixel Range <NSRANGEY> / <NSRANGEUV> 1 0 - 2
1 Noise Region 0 <NSREGIONY0> / <NSREGIONUV0> 12 0 - 1023
2 Noise Region 1 <NSREGIONY1> / <NSREGIONUV1> 24 0 - 1023
3 Noise Region 2 <NSREGIONY2> / <NSREGIONUV2> 40 0 - 1023
4 Noise Gain Level <NSFILTERY**> / <NSFILTERUV**> 100 0 - 255
Group 50 2:2pull down setting
0 22Film Mode Sensitivity Film Detection Sensitivity <FILMSTVT22> 4 1 - 5
1 22Film Mode Threshold Low <FILMTHRD22A> 80 0 - 32767
2 22Film Mode Threshold High <FILMTHRD22B> 120 0 - 32767
3 VOFTHR13 <VOFTHR13> 124 0 - 1023 * Read only
4 VOFTHR12 <VOFTHR12> 124 0 - 1023 * Read only
5 VOFTHR23 <VOFTHR23> 124 0 - 1023 * Read only
6 Video Motion Window Start X <VOFSTARX> 10 0 - 2047 Range of detective for Film mode
7 Video Motion Window Stop X <VOFSTOPX> 10 0 - 2047 Range of detective for Film mode
8 Video Motion Window Start Y <VOFSTARY> 10 0 - 1023 Range of detective for Film mode
9 Video Motion Window Stop Y <VOFSTOPY> 10 0 - 1023 Range of detective for Film mode
Group 51 2:3pull down setting
0 Global Motion Sensitivity Film Detection Sensitivity <FILMSTVT23> 4 1 - 5
1 Video Motion Sensitivity Film Detection Sensitivity <VOFSTVT> 4 1 - 5
2 Video Motion Threshold Low <VOFTHRDA> 120 0 - 32767
3 Video Motion Threshold High <VOFTHRDB> 180 0 - 32767
4 Global Motion Threshold <GMDTHRD> 124 0 - 1024
5 23Film Mode Threshold <FILMTHRD23> 100 0 - 32767
6 Global Motion Window Start X <GMDSTARX> 10 0 - 2047 Range of detective for Film mode
7 Global Motion Window Stop X <GMDSTOPX> 10 0 - 2047 Range of detective for Film mode
8 Global Motion Window Start Y <GMDSTARY> 10 0 - 1023 Range of detective for Film mode
9 Global Motion Window Stop Y <GMDSTOPY> 10 0 - 1023 Range of detective for Film mode
Group 60 Image
0 Center Contrast 578/578/534/534/492/492 0 - 1023
Video(S-Video) / Component / SCART /
ANALOG / DIGITAL / HDCP
Setting Value=
(MENU Value - MENU Center Value ) x
Alpha / 10 + Center
[Setting Value to PW]
Contrast [Max] 1023 [Min] 0
Brightness [Max] 1023 [Min] 0
Color [Max] 1023 [Min] 0
Tint [Max] 180 [Min] 0
Sharpness [Max] 57 [Min] 0
1 Center Brightness 512/512/512/500/512/512 0 - 1023
2 Center Color 512/534/512/512/512/512 0 - 1023
3 Center Tint 90/90/90/90/90/90 0-180
4 Center Sharpness 16/16/16/16/16/16 Fixed 16
5 Alpha Contrast 40/40/40/40/40/40 0-1000
6 Alpha Brightness 140/140/140/140/140/140 0-1000
7 Alpha Color 70/70/70/70/70/70 0-1000
8 Alpha Tint 10/10/10/10/10/10 0-1000
9 Alpha Sharpness 10/10/10/10/10/10 0-1000
Group 100 Panel Service
0 G-SubGain 512/524/472/472/512/524/485/472 0-1023
PCStandard/PCDynamic/PCReal/PCBlack-
Board/AVStandard/AVDynamic/AVCinema/
AVBlackBoard
1 R-SubGain 512/524/472/535/512/524/485/535 0-1023
2 B-SubGain 512/524/472/472/512/524/485/472 0-1023
3 G-SubBright 0/0/0/16/0/0/0/16 0-1023
PCStandard/PCDynamic/PCReal/PCBlack-
Board/AVStandard/AVDynamic/AVCinema/
AVBlackBoard
4 R-SubBright 0/0/0/16/0/0/0/16 0-1023
5 B-SubBright 0/0/0/16/0/0/0/16 0-1023
6 G-GammaShift 512/512 0-1023
PC/AV
Center=512
R] and [B] are linked with [G]
7 R-GammaShift 512/512 0-1023
8 B-GammaShift 512/512 0-1023
9 G-ReferH 1023/1023 0-1023
[R] and [B] are linked with [G] Scan Direction
(Front/Rear)
10 G-ReferL 336/336 0-1023
[R] and [B] are linked with [G] Scan Direction
(Front/Rear)
11 R-ReferH 1023/1023 0-1023 Scan Direction (Front/Rear)
12 R-ReferL 336/336 0-1023 Scan Direction (Front/Rear)
To Next Page
