Sanyo PLC-XT25 User Manual

-67-
Electrical Adjustment
Group/
Item
Item Name Function Initial Range Note
13 B-ReferH 1023/1023 0-1023 Scan Direction (Front/Rear)
14 B-ReferL 336/336 0-1023 Scan Direction (Front/Rear)
15 DXOutR 213 0-1023
16 DXOutG 213 0-1023
17 DXOutB 213 0-1023
18 H_Change_Pos 3 0-256
19 SH_Base 273 0-4095
20 NRG_Pos 50 0-128
21 NRG_Width 53 0-255
22 OSD_Pos 2 0-3
23 OSD_Ptn 0 0-7
24 GammaCtrl 1 0-1
25 REF_GatePos 4 0-1023
26 REF_GateDur 192 0-1023
27 R-BasePos 8 0-15
28 G-BasePos 8 0-15
29 B-BasePos 8 0-15
30 RGB-Adjust 0 0-7
31 RGB-AdjLv 0 0-1023
Operation STEP=256[0<->256<->512<->768
<->1023]
32 LineR0 8 0-255 (MIN<-->MAX Cyclic Operation)
33 LineR1 5 0-255 (MIN<-->MAX Cyclic Operation)
34 LineR2 4 0-255 (MIN<-->MAX Cyclic Operation)
35 LineR3 0 0-255 (MIN<-->MAX Cyclic Operation)
36 LineR4 0 0-255 (MIN<-->MAX Cyclic Operation)
37 LineG0 8 0-255 (MIN<-->MAX Cyclic Operation)
38 LineG1 5 0-255 (MIN<-->MAX Cyclic Operation)
39 LineG2 4 0-255 (MIN<-->MAX Cyclic Operation)
40 LineG3 0 0-255 (MIN<-->MAX Cyclic Operation)
41 LineG4 0 0-255 (MIN<-->MAX Cyclic Operation)
42 LineB0 8 0-255 (MIN<-->MAX Cyclic Operation)
43 LineB1 5 0-255 (MIN<-->MAX Cyclic Operation)
44 LineB2 4 0-255 (MIN<-->MAX Cyclic Operation)
45 LineB3 0 0-255 (MIN<-->MAX Cyclic Operation)
46 LineB4 0 0-255 (MIN<-->MAX Cyclic Operation)
47 GhostR-Pos 8 0-15
48 GhostG-Pos 8 0-15
49 GhostB-Pos 8 0-15
50 GhostR-Cent 0 0-2047
51 GhostR-Start 128 0-255
52 GhostR-End 128 0-255
53 GhostG-Cent 0 0-2047
54 GhostG-Start 128 0-255
55 GhostG-End 128 0-255
56 GhostB-Cent 0 0-2047
57 GhostB-Start 128 0-255
58 GhostB-End 128 0-255
59 BlockR1 0 0-2047 (MIN<-->MAX Cyclic Operation)
60 BlockG1 0 0-2047 (MIN<-->MAX Cyclic Operation)
61 BlockB1 0 0-2047 (MIN<-->MAX Cyclic Operation)
62 BlockR2 0 0-2047 (MIN<-->MAX Cyclic Operation)
63 BlockG2 0 0-2047 (MIN<-->MAX Cyclic Operation)
64 BlockB2 0 0-2047 (MIN<-->MAX Cyclic Operation)
65 ReverceR 0 0-2047 (MIN<-->MAX Cyclic Operation)
66 ReverceG 0 0-2047 (MIN<-->MAX Cyclic Operation)
67 ReverceB 0 0-2047 (MIN<-->MAX Cyclic Operation)
68 BackCrossR-Cent 0 0-2047
69 BackCrossR-Start 128 0-255
70 BackCrossR-End 128 0-255
71 BackCrossG-Cent 0 0-2047
72 BackCrossG-Start 128 0-255
73 BackCrossG-End 128 0-255
74 BackCrossBR-Cent 0 0-2047
75 BackCrossB-Start 128 0-255
76 BackCrossB-End 128 0-255
77 ColshdSelect 1 0-1
XT25 XT20
78 R-Min 383 340 0-1023
79 R-Mid2 485 466 0-1023
80 R-Mid1 574 570 0-1023

Sanyo PLC-XT25 Specifications

General

Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Resolution	1024 x 768 pixels
Dimensions (WxDxH)	302 x 422 x 162 mm
Display diagonal	1 \
Lamp type	UHP
Lamp power	300 W
Light source type	Lamp
Market positioning	Portable

Weight and Dimensions

Weight	9200 g
