108 Cubis MSE Operating Instructions
Accessories (Options)
Accessories (Options)
Printers and Communication
Verifiable data printer for connection to RS-232, 25-pin� Accessory interface YDP10-0CE
Verifiable data printer with
Bluetooth
®
data transmission (with YDO01MS-B or IB option only) YDP10BT-0CE
Color ribbon for YDP10-0CE and YDP10BT-OCE 6906918
Paper rolls for printer YDP10-0CE; 5 rolls 50 m each 6906937
Bluetooth
®
data interface for wireless connection of data printer YDP10BT YDO01MS-B
RS-232C data interface, 9-pin including PS/2 for connecting a PC or keyboard YDO01MS-P
RS-232C data interface, 25-pin for connection of Cubis
®
accessories YDO01MS-R
Display cable 3 m for Cubis
®
MSE models, for separate setup of display and weighing unit
(Installation by Sartorius Service or ex works [order VF4016])
YCC01-MSED3
Cable 3 m between weighing module and electronics module for Cubis
®
models with 0�01 mg readability YCC01-MSM3
Installation display cable 3 m for Cubis
®
models, for separate setup of display and weighing unit VF4016
RS-232C connection cable to connect PC with 9-pin� COM interface, length 1�5 m 7357314
SartoCollect software for data communication between balance and PC YSC02
Sartorius OPC Server for connecting all Sartorius Cubis
®
balances
Requires 32-bit Microsoft Windows 2000 or XP with current service packs�
(free download of a 30-day trial version from the Sartorius website)
– Initial license
– Each additional license within an order
6289OPC
6289OPC-L
Displays and Input | Output Elements
MSA control unit with color TFT graphic display and touch screen YAC01MSA
MSE display unit with backlit LC display and tactile keys YAC01MSE
MSU display and control unit with backlit b | w graphic display and tactile navigation keys YAC01MSU
Barcode reader with connection cable, 120 mm reading range YBR03PS2
Foot switch for printing, taring, or using function keys, selection via menu, incl� T connector YFS01
Infrared sensor for touch-free activation of functions (e�g�, draft shield control) YHS01MS
Hand switch for printing, taring, or using function keys, selection via menu, incl� T connector YHS02
Foot switch for functions draft shield OPEN | CLOSED (in combination with DA and DI draft shields only), tare, and
print
YPE01RC
Additional display, LCD, figure size 13 mm, backlit YRD03Z
3-segment control display, red – green – red, for plus|minus measurements, incl� T connector YRD11Z
