Sartorius Cubis Series Operating Instructions

Getting Started
Cubis MSE Operating Instructions 21
Modification Options
Setting Up the Display and Control Unit at the Place of Use
The display and control unit can be removed for all models to enable the operator
to customize the work space�
Removing the Retainer with the Display and Control Unit
t Remove all items (such as weights) from the draft shield�
t Carefully remove all parts as shown in the illustration�
1. Weighing pan
2. Pan support (not for MSE225… MSE125… models)
3. Shield plate/Draft shield
t Keep all parts in a safe place�
t Remove the panels (right and left)�
Models with the analytical draft shield:
1. Press on the locking tab�
2. Remove the panel�
Models with the milligram draft shield:
1. Press on the locking tab�
2. Remove the panel�
t Keep all parts in a safe place�
2
1
3
2
1
2
1

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
