Page #56 background imageLoading...
Page #56 background image
Application Programs
56 Cubis MSE Operating Instructions
Net-total Formulation
Display symbol: +
Purpose
This application can be used to weigh different components up to a defined
total� You can print out both the total weight and the individual weights of the
components�
Features
Weigh up to 99 components from “0” to a defined total component weight�
Save component weights (“Store xx comp�”), with
– display zeroed automatically after value is stored, and
– automatic printout
Clear component memory following cancellation of the weighing sequence by
pressing F and print the total weight�
Toggle between component weight and total weight by pressing and holding
the S key�
Print the total of the individual component weights T-Comp)
Preparation
§ Select the “Net-total Formulation” application in the menu:
See “Configuration”
§ Configuring parameters:
Applic. Application programs
Net-Totl. Net-total formulation
Comp.Prt. Printout of components
Off
o On
o = Factory settings
Net-total formulation printout
Comp 2+ 278.1 g : Second component weight
T-Comp+ 2117.5 g : Total components

Other manuals for Sartorius Cubis Series

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sartorius Cubis Series and is the answer not in the manual?

Sartorius Cubis Series Specifications

General IconGeneral
DisplayColor touch screen
Readability0.01 mg to 1 g
InterfacesUSB, Ethernet, RS-232
CalibrationInternal and external
HousingDie-cast aluminum
Response TimeVaries by model
Pan SizeVaries by model
Operating Temperature10°C to 30°C
ComplianceGLP
Power Supply100 – 240 V, 50/60 Hz
CapacityVaries by model (up to 64 kg)
RepeatabilityVaries by model
LinearityVaries by model
