Sartorius Cubis Series Operating Instructions

Application Programs
52 Cubis MSE Operating Instructions
Calculation
Display symbol: /
Purpose
With this application, you can calculate weight values using
a multiplier or divisor�
This can be used, for example, to determine the weight per unit area, or “gsm”
weight (grams per square meter), of paper�
Setting the Factor or Divisor
Activate function:
Press the S key
Select a number of up to 8 digits and, if needed, one decimal point
(0�0000001–99999999):
In increments of one: Press the S key briefly
To increase the value without pressing repeatedly: Press and hold the S key
The selected operator is saved to protected memory�
Preparation
§ Select the “Calculation” application in the menu:
See “Configuration”
§ Configuring parameters:
Applic. Application programs
Calc. Calculation
Method (Operator)
o Mul. Multiplier
Div. Divisor
DEC.PLCS Number of decimal places
none No dec� places
o 1 dec.pl. 1 decimal place
2 Dec.Pl. 2 decimal places
3 Dec.Pl. 3 decimal places
o = Factory settings
Calculation printout
Mul + 1.2634 : Multiplier
Div + 0.6237 : Divisor
Res + 79.7 o : Result

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
