Sartorius Cubis Series Operating Instructions

Application Programs
50 Cubis MSE Operating Instructions
Weighing in Percent
Display symbol: %
Purpose
This application allows you to obtain weight readouts in percent which are in
proportion to a reference weight�
Changing the reference percentage value
Activate function:
Press the S key
Select the desired reference quantity (1 to 100):
In increments of one: Press the S key briefly
In increments of ten: Press and hold the S key
The selected percentage is saved to protected memory�
Preparation
§ Select the “Weighing in Percent” application in the menu:
See “Configuration”
§ Configuring parameters:
Applic. Application programs
Percent Weighing in Percent
DEC.PLCS Number of decimal places
none No dec� places
o 1 dec.pl. 1 decimal place
2 Dec.Pl. 2 decimal places
3 Dec.Pl. 3 decimal places
o = Factory settings
Weighing in percent printout
pRef 100 % : Reference percentage
Wxx% 111.6 g : Reference weight net xx% for selected
reference percentage
Prc + 94.9 % : Calculated reference percentage

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
