Safety Instructions
6 Cubis MSE Operating Instructions
Intended Use
Cubis models are high-resolution balances� They were specially
developed for exact determination of material mass in liquid,
paste, powder or solid form�
Appropriate containers must be used for each type of sample
material�
Specific models cover specific weighing ranges: see
“Specifications�"
Cubis models are designed specially for use in research,
education and day-to-day laboratory tasks in science and
industry�
They are designed to be used exclusively indoors�
Cubis models can be operated as standalone, connected to a
PC, or on a network�
General View of the Equipment and Equipment Supplied
Balances with a readability of ≤ 1 µg
Pos� Description
1 Weighing pan
2 Filter weighing pan d 50 mm
3 Internal draft shield (for MSx2�7S-F only)
4 Optional weighing pan d 75 mm
5 Shield disk
6 Optional filter weighing pan d 90 mm
7 Shield plate
8 Level indicator
9 Leveling foot
10 MSE2�7�� model: bush
11 Draft shield cover
Pos� Description
12 Female connector for weigh cell
13 DC jack
14 Display and control unit
15 Serial communications port (PERIPHERALS)
16 Slot for optional interfaces, e� g� 9-pin data output or Bluetooth�
PS2 socket has no function�
17 Lug for attaching antitheft locking device
18 Equipotential bonding conductor terminal
19 Equipotential bonding conductor terminal
20 Draft shield
Not shown: AC adapter, USB cable
Use 69719
87
1
2
3
4
5
6
7
8
9
11
12
13
14
15
16
17
18
19
7
1
3
20
10
10

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
