Operation
Cubis MSE Operating Instructions 35
Internal Calibration/Adjustment
Configuration:
SETUP - Bal.Scal- CAL./ADJ. - Cal.Int.
The balance housing has a built-in calibration/adjustment
weight�
§ Select Calibration/Adjustment: (CAL) key
> The internal calibration weight is automatically loaded
> The balance is calibrated
> When the setup is configured to “Calibration and
adjustment in one,” the balance will be adjusted
automatically
> The internal calibration weight is removed
Performing Calibration and Adjustment Routines
The following settings can be configured:
– Always perform calibration and adjustment in one
routine (factory setting)
– After calibration, the user has the option to quit the
routine without correction or to adjust the balance
If no deviations are found during calibration, the calibration/
adjustment routine can be exited after the calibration is
completed�
Two keys are now active:
– The (CAL) key for initiating the adjustment routine
– The (CF) key for exiting the routine
Step Key Display/
Printout
1� Tare the balance J 0.0 g
2� Start the calibration process C CAL.Int.
Internal weight is CAL.RUN.
applied automatically
3� Calibration/Adjustment CAL.end
executed
4� The internal weight is
removed 0.0 g
External Calibration
Configuration:
SETUP - Bal.Scal- CAL./ADJ. - Cal.Ext.
The balance has a factory-set calibration weight value (see
“Specifications”)�
Step Key Display/
Printout
1� Tare the balance J 0.0 g
2� Start the calibration process C CAL.ext.
Once you store the zero - 5000.0 g
point, the display prompts
for the required calibration
weight (flashing display)�
3� Place displayed calibration 5000.0 g
weight on balance (in this
example: 5000 g)�
Weight too low:
a minus sign “-" is shown
Weight too high:
a plus sign “+" is shown
The display stops flashing
as soon as the weight value
is within the defined limit�
4� Calibration/Adjustment Cal.end
executed; then the calibration
weight value is displayed +5000.0 g
5� Remove calibration weight 0.0 g
