Sartorius Cubis Series Operating Instructions

90 Cubis MSE Operating Instructions
Technical Specifications
Model-specific Data
Precision balances
Models MSE5203S MSE5203P MSE3203S MSE3203P
Readability mg 1 1/2/5 1 1/10
Weighing capacity g 5,200 1,200/2,400/5,200 3,200 1,010/3,200
Tare range (subtractive) g – 5,200 – 5,200 – 3,200 – 3,200
Repeatability <±mg 1 1 1 1/6
Linearity <±mg 5 5 5 5
Corner load (test load [g]) mg 2 (2,000) 2 (2,000) 2 (1,000) 2 (1,000)
Optimal starting point
of the measuring range* g 0�82 0�82 0�82 0�82
Sensitivity drift between +10 to +30°C ±ppm/K 1 1 1 1
Typical stabilization time s < 1 < 1 < 1 < 1
Typical measurement time s < 2 < 2 < 2 < 1�5
External standard calibration value g 5,000 5,000 2,000 2,000 (E2)
(min� accuracy class)
Display result
(depending on the set filter level) 0�1 – 0�4
Weighing pan size (W + D) mm 140 + 140
Weighing chamber height
(draft shield DE) mm 172
Protection Protected against dust and water
* = According to USP (United States Pharmacopeia) section 41, the optimal measuring range is defined from 820 d to the max� weighing
range� Typically the value can be higher depending on the setup location and the ambient conditions�
Models MSE2203S MSE2203P MSE1203S
Readability mg 1 1/10 1
Weighing capacity g 2,200 1,010/2,200 1,200
Tare range (subtractive) g – 2,200 – 2,200 – 1,200
Repeatability <±mg 1 1/6 0�7
Linearity <±mg 3 5 2
Corner load (test load [g]) mg 2 (1,000) 3 (1,000) 2 (500)
Optimal starting point
of the measuring range* g 0�82 0�82 0�82
Sensitivity drift between +10 to +30°C ±ppm/K 1 1 1�5
Typical stabilization time s < 1 < 1 < 1
Typical measurement time s < 1�5 < 1�5 < 1�5
External standard calibration value g 2,000 (E2) 1,000 (E2) 1,000 (E2)
(min� accuracy class)
Display result
(depending on the set filter level) 0�1 – 0�4
Weighing pan size (W + D) mm 140 + 140
Weighing chamber height
(draft shield DE) mm 172
Protection Protected against dust and water
* = According to USP (United States Pharmacopeia) section 41, the optimal measuring range is defined from 820 d to the max� weighing
range� Typically the value can be higher depending on the setup location and the ambient conditions�

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
