Sartorius QC7CCE-D User Manual

Mounting the Raised Display Unit on the Long Side
of the Scale
Please be careful that the scale does not fall over
when disassembling and mounting the parts as
described here and in the following steps. Follow the
instructions given on page1–12 before you begin
to change the display mounting.
Lay the scale on its side to disassemble and mount the
display unit.
Unfasten the Allen screws on the base plate
and remove the base plate.
Remove the fastening screws.
1–16
