Mounting the Remote Display Unit (Option)
(only possible with the optional display holder;
order no. YDH01TS)
Note:
You can also mount the display as a remote unit
for the QC 7 model.
!
Please be careful that the scale does not fall over
when disassembling and mounting the parts as
described here and in the following steps. Follow the
instructions given on page1–12 before you begin to
change the display mounting.
Lay the scale on its side to disassemble and mount
the parts.
Unfasten the Allen screws on the base plate
and remove it.
Remove the screws on the retainer plate.
1–19
