Remove the screws on the base (7) (see diagram
on the left).
Then set the scale back upright.
Remove the fastening screws.
Lay the support arm along with the base and the
display unit on a table.
Unfasten the screws on the display unit (5) and remove
the retainers.
Slide the clips which hold down the cable in the
raceway up and out of the support arm.
