Satec PM135EH User Manual

Chapter 1 General Information Measured Parameters
PM135 Powermeter Series 17
Parameter
Display
Comm.
Analog
Pulse
Alarm
Ampere Maximum Demand per phase



Voltage Maximum Demand per phase



Power Demands
E, EH
kW Accumulated Demand Import & Export



kvar Accumulated Demand Import & Export



kVA Accumulated Demand



kW Demand Import & Export


kvar Demand Import & Export


kVA Demand


kW Sliding Demand Import & Export


kvar Sliding Demand Import & Export


kVA Sliding Demand


kW Predicted Demand Import & Export


kvar Predicted Demand Import & Export


kVA Predicted Demand


kW Maximum Demand Import


kW Maximum Demand Export


kvar Maximum Demand Import


kvar Maximum Demand Export


kVA Maximum Demand


Total Energy
E, EH
Total kWh Import & Export



Total kvarh Import & Export



Total kvarh Net

Total kVAh



Energy per Phase
E, EH
kWh Import per phase


kvarh Import per phase


kVAh per phase


TOU Registers
E, EH
4 TOU energy registers (kWh and kvarh
import & export, kVAh, 4 pulse sources)


4 TOU maximum demand registers


8 tariffs, 4 seasons x 4 types of day



Harmonic Measurements
EH
Voltage THD per phase



Current THD per phase



Current TDD per phase



K-factor per phase



Voltage harmonics per phase up to order 40


Current harmonics per phase up to order 40


Voltage harmonic angles up to order 40


Current harmonic angles up to order 40


Fundamental Component
EH
Voltage and Current per phase


kW, PF per phase


kvar, KVA per phase


Total kW, PF


Total kvar, KVA


Min/Max Logging
Min/Max A, V, total kW, kvar, kVA, PF



Satec PM135EH Specifications

General

Brand	Satec
Model	PM135EH
Category	Measuring Instruments
Language	English
