Appendix D Parameters for Monitoring and
Data Logging
150
Series PM175 Powermeters
Appendix D Parameters for Monitoring and
Data Logging
The following table lists parameters measured by the meter
that are available for data logging and monitoring through
communications. The left column shows data abbreviations
used in PAS. Parameter groups are highlighted in bold.
Designat
ion
Description
NONE
None (stub, read as zero)
EVENT
FLAGS
Event Flags
EVENT
FLAGS
1:16
Event Flags #1-#8
DIGITAL
INPUTS
Digital Inputs
DI1:16
Digital Inputs Status DI1:DI2
RELAYS
Relays
RO1:16
Relay Status RO1:RO2
COUNTE
RS
Pulse Counters
COUNTER
1
Counter #1
COUNTER
2
Counter #2
COUNTER
3
Counter #3
COUNTER
4
Counter #4
SYMM
COMP
Symmetrical Components
V PSEQ
Positive-sequence voltage
V NSEQ
Negative-sequence voltage
V ZSEQ
Zero-sequence voltage
V NSEQ
UNB%
Negative-sequence voltage unbalance
V ZSEQ
UNB%
Zero-sequence voltage unbalance
I PSEQ
Positive-sequence current
I NSEQ
Negative-sequence current
I ZSEQ
Zero-sequence current
I NSEQ
UNB%
Negative-sequence current unbalance
I ZSEQ
UNB%
Zero-sequence current unbalance
RT
PHASE
1-Cycle Phase Values
V1
V1/V12 Voltage
1
V2
V2/V23 Voltage
1
V3
V3/V31 Voltage
1
I1
I1 Current
I2
I2 Current
I3
I3 Current
kW L1
kW L1
kW L2
kW L2
kW L3
kW L3
kvar L1
kvar L1
kvar L2
kvar L2
kvar L3
kvar L3
kVA L1
kVA L1
