Entering the Password
The Setup Change menu can be secured by a four-digit user
password. The meter is primarily shipped with the password
preset to 0 and password protection disabled. You can change
the password and enable password protection through the
Access Control menu (see Meter Security).
If authorization is not required, just press the ENTER button to
move to the Main menu; otherwise you should enter a correct
password to be authorized to access the meter setup.
To enter the password:
1. Adjust the first digit with the UP and DOWN arrow
buttons.
2. Press the SELECT button to advance to the next digit.
3. Adjust the remaining password digits in the same manner.
4. Press ENTER to confirm the password.
If the password entered is correct, you move to the Main
menu, otherwise you return to the previous menu.
Selecting the OPS or CHG entry moves you to the Main menu
that is represented by two entries: the upper window displays
a secondary menu list, while the bottom item is an assisting
exit window.
Selecting a Menu Entry
To select a menu entry from the menu list:
1. Highlight the upper item by pressing the SELECT button.
2. Scroll through the menu list by pressing briefly the UP and
DOWN arrow buttons until the desired menu entry
appears.
3. Press the ENTER button.
Viewing and Changing Setup Items
A second level menu normally consists of three items: the
upper static window indicates the menu name, while the
middle window represents a list of setup parameters you can
scroll through, and the lower item shows the present
parameter value.
To select a parameter you want to view or change:
1. Highlight the middle window by pressing the SELECT
button.
