Chapter 3 Display Operations
Menu Operations
Series PM175 Powermeters
51
Analog Outputs Setup
This entry appears only if the meter is ordered with optional
analog outputs. For more information on configuring analog
inputs in your meter, see Programming Analog Outputs in
Chapter 4.
To enter the menu, select the “A.Ou.1” or “A.Ou.2” entry from
the Main menu for the AO1 and AO2 output respectively, and
then press the ENTER button.
To change the analog output options:
1. Use the UP and DOWN arrow buttons to scroll to the
desired parameter.
2. Press the SELECT button to activate the lower window.
3. Use the UP and DOWN arrow buttons to adjust the
parameter value.
4. Press ENTER to confirm the new parameter setting, or
press ESC to discard changes.
5. You are returned to the middle window to select another
parameter, or store your new settings and exit the menu.
To store new settings and exit the menu:
1. When the middle window is highlighted, press the ENTER
button.
2. You return to the Main menu.
To exit the menu without saving your changes, press ESC.
The following table lists available analog output options. For a
list of the available output parameters and their scales, see
Programming Analog Outputs in Chapter 4.
Label
Parameter
Options
Description
OutP
Output
parameter
See Appendix B
Selects the measured parameter to
be transmitted through the analog
output channel.
Lo
Zero scale
Low engineering scale (in primary
units) for the analog output
corresponding to a lowest (zero)
output current (0 or 4 mA)
Hi
Full scale
High engineering scale (in primary
units) for the analog output
corresponding to a highest output
current (1 or 20 mA)
A.Ou.1
ESC
A.Ou.1
rt.U1
OutP
A.Ou.1
0
Lo
A.Ou.1
230
Hi
