Satec PM175 User Manual

Chapter 2 Installation
Electrical Installation
Series PM175 Powermeters
19
Terminals
+RX
16
RS-422/RS-485
POWER SUPPLY
-RX-TX +TX
VN
9 6
1413 15
11
5
V
3
8
Handle Only at
COM.1
1
Workstations
Static-Safe
COM.2
Static-Sensitive
Devices
ATTENTION
17
N/-
L/+
12
10
9
2
1
10-16VDC
18-36VDC
36-72VDC
2
V
5
(24)
(48)
(12)
O
S/N
S
N
LOW DC
CT.
I
1A
T
DIGITAL INPUTS
90-264VAC
50/60Hz
85-290VDC
POWER SUPPLY
V
1
2
10W
O
P
ANALOG OUTPUTS
2018 19
1 2
23
+
21 22
+
262524
3
7
6
2
4
1
-
3
RELAYS
+
1
292827
21
ANALOG INPUTS
ANALOG IN/OUT :
+1mA
-
0-20mA
4-20mA
0-1mA
+
+
-
-
- -
CALIBRATED AT :
25 Hz
60 Hz
50 Hz
400 Hz
COM.1 :
RS-232/422/485 STANDARD
ETHERNET
MODEM
PROFIBUS
690V
OPT.U
STANDARD
CT.
5A
Figure 2-16 Terminals - Rear View
Power Source Connection
Before connecting your meter to the power source, check the
label on the back of the device to ensure that it is equipped
with the appropriate power supply.
The power source can be dedicated-fused, or from a
monitored voltage if it is within the instrument power supply
range.
AC power supply: connect the line wire to terminal 12 and the
neutral wire to terminal 10.
DC power supply: connect the positive wire to terminal 12 and
the negative wire to terminal 10.
Chassis Ground Connection
Connect the chassis ground of the device to the switchgear
earth ground using a dedicated wire greater than 2 mm
2
/14
AWG.
Chassis Ground
AC Voltage
Inputs
Digital
Inputs
Analog Inputs/Outputs
Relay Outputs
AC Current Inputs
COM1 Port
COM2 Port
Power Supply
