Satec PM175 User Manual

Appendix D Parameters for Monitoring and
Data Logging
152
Series PM175 Powermeters
Designat
ion
Description
I2 THD
I2 Current THD
I3 THD
I3 Current THD
I1 KF
I1 K-Factor
I2 KF
I2 K-Factor
I3 KF
I3 K-Factor
I1 TDD
I1 Current TDD
I2 TDD
I2 Current TDD
I3 TDD
I3 Current TDD
V12
V12 Voltage
V23
V23 Voltage
V31
V31 Voltage
AVR
TOTAL
1-Second Total Values
kW
Total kW
kvar
Total kvar
kVA
Total kVA
PF
Total PF
PF LAG
Total PF lag
PF LEAD
Total PF lead
kW IMP
Total kW import
kW EXP
Total kW export
kvar IMP
Total kvar import
kvar EXP
Total kvar export
V AVG
3-phase average L-N/L-L voltage
1
V LL AVG
3-phase average L-L voltage
I AVG
3-phase average current
AVR AUX
1-Second Auxiliary Values
In
In (neutral) Current
FREQ
Frequency
V UNB%
Voltage unbalance
I UNB%
Current unbalance
RMS
(10-min)
10-min Volts and Symmetrical
Components
V1
V1/V12 Voltage
2
V2
V2/V23 Voltage
2
V3
V3/V31 Voltage
2
V ZERO-
SEQ
Zero-sequence voltage
I ZERO-
SEQ
Zero-sequence current
V UNB%
Negative-sequence voltage unbalance
I UNB%
Negative-sequence current unbalance
HRM
TOT (10-
min)
10-min Total Harmonics
V1 THD
V1/V12 Voltage THD
2
V2 THD
V2/V23 Voltage THD
2
V3 THD
V3/V31 Voltage THD
2
I1 THD
I1 Current THD
I2 THD
I2 Current THD
I3 THD
I3 Current THD
V1 THD/I
V1/V12 Interharmonic voltage THD
2
V2 THD/I
V2/V23 Interharmonic voltage THD
2
V3 THD/I
V3/V31 Interharmonic voltage THD
2
I1 TDD
I1 Current TDD
I2 TDD
I2 Current TDD
I3 TDD
I3 Current TDD
PHASOR
S
Phasors
V1 Mag
V1/V12 Voltage magnitude
2
V2 Mag
V2/V23 Voltage magnitude
2
V3 Mag
V3/V31 Voltage magnitude
2
