Satec PM175 User Manual

Appendix D Parameters for Monitoring and
Data Logging
Series PM175 Powermeters
161
Designat
ion
Description
TOU
REG7
TRF1
Tariff #1 register
TOU
REG7
TRF2
Tariff #2 register
…
…
TOU
REG7
TRF8
Tariff #8 register
TOU
REG8
TOU Energy Register #8
TOU
REG8
TRF1
Tariff #1 register
TOU
REG8
TRF2
Tariff #2 register
…
…
TOU
REG8
TRF8
Tariff #8 register
TOU
MAX
DMD
REG1
TOU Maximum Demand Register #1
DMD1
TRF1 MAX
Tariff #1 register
DMD1
TRF2 MAX
Tariff #2 register
…
…
DMD1
TRF8 MAX
Tariff #8 register
TOU
MAX
DMD
REG2
TOU Maximum Demand Register #2
DMD2
TRF1 MAX
Tariff #1 register
DMD2
TRF2 MAX
Tariff #2 register
…
…
DMD2
TRF8 MAX
Tariff #8 register
TOU
MAX
DMD
REG3
TOU Maximum Demand Register #3
DMD3
TRF1 MAX
Tariff #1 register
DMD3
TRF2 MAX
Tariff #2 register
…
…
DMD3
TRF8 MAX
Tariff #8 register
TOU
MAX
DMD
REG4
TOU Maximum Demand Register #4
DMD4
TRF1 MAX
Tariff #1 register
DMD4
TRF2 MAX
Tariff #2 register
…
…
DMD4
TRF8 MAX
Tariff #8 register

Satec PM175 Specifications

General

Communication Ports	RS-485, Ethernet
Display	LCD with backlight
Frequency Range	45-65 Hz
Installation	Panel mount
Current Input	1A or 5A via CT; Burden: <0.2VA per phase
Communication Protocols	Modbus RTU, Modbus TCP
Accuracy	Class 0.2S
Power Supply	85-265V AC/DC
