Satec PM175 User Manual

Appendix E EN50160 Statistics Log Files
166
Series PM175 Powermeters
Field No.
Designation
Description
3
N1
Number of polyphase incidents, N1
4
N1/N, %
EN50160 compliance ratio, N1/N
5
V1 N1
Number of incidents on phase V1
6
V1 Frq1 %Un
Maximum 1st signaling voltage magnitude on phase V1, %Un
7
V1 Frq2 %Un
Maximum 2nd signaling voltage magnitude on phase V1, %Un
8
V1 Frq3 %Un
Maximum 3rd signaling voltage magnitude on phase V1, %Un
9
V1 Frq4 %Un
Maximum 4th signaling voltage magnitude on phase V1, %Un
10
V2 N1
Number of incidents on phase V2
11
V2 Frq1 %Un
Maximum 1st signaling voltage magnitude on phase V2, %Un
12
V2 Frq2 %Un
Maximum 2nd signaling voltage magnitude on phase V2, %Un
13
V2 Frq3 %Un
Maximum 3rd signaling voltage magnitude on phase V2, %Un
14
V2 Frq4 %Un
Maximum 4th signaling voltage magnitude on phase V2, %Un
15
V3 N1
Number of incidents on phase V3
16
V3 Frq1 %Un
Maximum 1st signaling voltage magnitude on phase V3, %Un
17
V3 Frq2 %Un
Maximum 2nd signaling voltage magnitude on phase V3, %Un
18
V3 Frq3 %Un
Maximum 3rd signaling voltage magnitude on phase V3, %Un
19
V3 Frq4 %Un
Maximum 4th signaling voltage magnitude on phase V3, %Un
20
Frq1
1st signaling voltage frequency
21
Frq2
2nd signaling voltage frequency
22
Frq3
3rd signaling voltage frequency
23
Frq4
4th signaling voltage frequency
EN50160 Harmonics Survey Log (Data Log #10)
Field No.
Designation
Description
V1 Harmonic Voltage
1
THD MAX
Maximum THD
2
THDO MAX
Maximum odd harmonics THD
3
THDE MAX
Maximum even harmonics THD
4
%HD02 MAX
Maximum H02 harmonic voltage magnitude, %Un
5
%HD03 MAX
Maximum H03 harmonic voltage magnitude, %Un
…
…
51
%HD50 MAX
Maximum H50 harmonic voltage magnitude, %Un
V2 Harmonic Voltage
1
THD MAX
Maximum THD
2
THDO MAX
Maximum odd harmonics THD
3
THDE MAX
Maximum even harmonics THD
4
%HD02 MAX
Maximum H02 harmonic voltage magnitude, %Un
5
%HD03 MAX
Maximum H03 harmonic voltage magnitude, %Un
…
…
51
%HD50 MAX
Maximum H50 harmonic voltage magnitude, %Un
V3 Harmonic Voltage
1
THD MAX
Maximum THD
2
THDO MAX
Maximum odd harmonics THD
3
THDE MAX
Maximum even harmonics THD
4
%HD02 MAX
Maximum H02 harmonic voltage magnitude, %Un
5
%HD03 MAX
Maximum H03 harmonic voltage magnitude, %Un
…
…
51
%HD50 MAX
Maximum H50 harmonic voltage magnitude, %Un
