SATEL Installation and Programming Manual 27
DHCP
IP address
Subnet mask
Gateway
Change code
Exit programmin
Entering names and numerical values
The flashing cursor indicates the character which is currently being edited. The and
buttons allow you to scroll through the letters/numbers that can be entered. The
button
moves the cursor to the right, and the
button – to the left. If the cursor indicates the first
character to be edited, pressing the button will exit the function. If the cursor indicates
the last character, pressing the
button will exit the function. If you have made any
changes, after exiting the function you will be asked whether to save changes (use the
button to go back to the function, the button – to cancel the changes, and the button
– to save the changes).
Selecting from single selection list
The upper display line shows the function name, and the lower – the currently selected
parameter. The and buttons allow you to scroll through the list of parameters.
Pressing the or button will exit the function. If you have made any changes, after
exiting the function you will be asked whether to save changes (use the button to go
back to the function, the
button – to cancel the changes, and the button – to save the
changes).
Selecting from multiple selection list
The upper display line shows the function name, and the lower – one of the items that can be
selected. Use the and buttons to scroll through the list. An additional symbol is
shown in the upper right corner of the display:
– displayed item is selected;
– displayed item is not selected.
Pressing the button will change the currently displayed symbol to the other one. Use the
button to exit from the function. If you have made any changes, after exiting the function
you will be asked whether to save changes (use the
button to go back to the function, the
button – to cancel the changes, and the button – to save the changes).
