SATEL Installation and Programming Manual 3
1. Introduction
This manual covers the following microprocessor based fire alarm control panels:
CSP-104 - 4 zone conventional fire alarm control panel,
CSP-108 - 8 zone conventional fire alarm control panel,
CSP-204 - 4 zone conventional fire alarm control panel with LCD display,
CSP-208 - 8 zone conventional fire alarm control panel with LCD display.
The manual also describes the optional components of the fire alarm control panel, i.e.
repeater panels and CSP-ETH module for communication with virtual panel.
Prior to installation, read this manual carefully in order to avoid mistakes and errors which
might result in malfunctioning of or even damage to the equipment. The manual contains
guidelines for installation of the fire alarm control panel, its programming and connecting
other devices to it. This manual describes no principles of designing the fire detection and fire
alarm systems.
2. Function of the fire alarm control panels
The CSP-104, CSP-108, CSP-204 and CSP-208 control panels are designed for:
 supervision of the operation of detectors and manual call points;
 supervision of the operation of other external devices;
 control of sounders;
 control of fire alarm and fault warning routing equipment;
 control of other external devices.
The above functions make it possible to detect a fire at its earliest stages of development and
inform the building users about the fact with the use of acoustic and/or optical signaling, as
well as to notify the appropriate services. This enables an early fire fighting action to be
taken. The system can also automatically start the appropriate fire protection equipment.
3. Features
 4 (CSP-104 and CSP-204) or 8 (CSP-108 and CSP-208) zones.
 Support for up to 32 detectors or 10 manual call points (MCP) by each zone.
 Coincidence detection (type A and type B dependencies).
 4 programmable inputs (including confirmation of fire alarm and fault warning
transmissions).
 2 outputs dedicated to control of sounders.
 Output to fire alarm routing equipment.
 Output to fault warning routing equipment.
 Signal delay at the outputs.
 Extended control panel and system testing functions.
 Communication bus to enable connection of:
 a repeater panel;
 the CSP-ETH module for communication with the virtual panel.
 Power output 24 V.
 Dedicated output for power supply of the CSP-ETH module.
