48 CSP-204 ● CSP-208 ● CSP-104 ● CSP-108 SATEL
Power supply overcurrent protection....................................................... slow-blow fuse 3.15 A
Current parameters of integrated power supply (acc. to EN54-4):
Imax a .............................................................................................................. 2.5 A
Imax b .............................................................................................................. 3.6 A
Backup power supply:
internal lead-acid battery...................................12 V / 17 Ah e.g. HV17-12W KOBE
Backup battery life .............................................................................................................. 72 h
Battery charging current, max .............................................................................................. 1 A
Maximum battery internal resistance (with wires and terminals in circuit) ............................ 1 Ω
Current consumption from battery – quiescent condition .................................................60 mA
Current consumption from battery – fire alarm condition..................................................60 mA
Current consumption from integrated power supply – quiescent condition ......................55 mA
Current consumption from integrated power supply – fire alarm condition ......................55 mA
Enclosure protection rating ................................................................................................ IP30
Maximum humidity ..........................................................................................................93±3%
Operating temperature range................................................................................... -5…+40 °C
Transportation temperature range ........................................................................ -25….+55 °C
Dimensions ............................................................................................... 324 x 382 x 108 mm
Weight without battery...................................................................................................... < 3 kg
12.3 CSP-ETH module
Maximum current consumption ........................................................................................45 mA
Maximum humidity ..........................................................................................................93±3%
Operating temperature range................................................................................... -5…+40 °C
Transportation temperature range ........................................................................ -25….+55 °C
Electronics board dimensions ................................................................................. 60 x 50 mm
Weight.................................................................................................................................24 g
