2. After a few seconds:
the red LED designated with a digit corresponding to the zone number should
start blinking;
the red LED described as FIRE should start blinking (in the case of a type B
dependent zone, the LED should remain OFF);
an acoustic signal should be heard.
Note: Additionally, the alarm triggering should result in activation of the sounders, fire alarm
routing output and relay outputs, if this is provided for by the control panel
configuration.
3. Press the button to silence the control panel acoustic signaling.
4. Turn the key switch to the position designated by the symbol to get access at level
2.
5. Press the button to clear the alarm (if an MCP is activated, you must reset it
first).
6. Repeat the operations described in steps 1-5 for the other zones.
11. Maintenance
The fire alarm system requires a regular maintenance. It is recommended that the periodical
tests be carried out at least once a year. For spaces with harsh environment (e.g. due to
dustiness, aggressive conditions which may cause corrosion, etc.), the frequency of
periodical tests should be increased.
Within the maintenance work, you are to perform the following operations:
1. Carry out a test for control panel LEDs and acoustic signaling.
2. Read the events logged into the control panel memory.
3. Check the condition of control panel battery.
4. Check that, after loss of the 230 V AC mains supply, the control panel will automatically
switch over to the backup power supply.
5. If a repeater panel is connected to the control panel, repeat for the repeater panel the
operations described in points 1, 3 and 4.
6. Perform a visual control of all detectors and MCPs.
7. Carry out a test for detectors and MCPs.
8. Carry out a test for sounders.
9. Carry out a test for routing outputs.
11.1 Fuse replacement in the battery charging system
The battery charging system in control panels and repeater panels is protected by a SSTC
3.5 slow-blow fuse, manufactured by Bel Fuse, rated at 3.5 A. Location of the fuse is shown
in Fig. 24. If the fuse blows, replace it with a new one. The fuses are available in product
portfolio offered by SATEL.
