SATEL Installation and Programming Manual 13
7. At the marked places, drill holes for wall plugs (the wall plugs are delivered with the
control panel).
8. Run the cables through the holes at the enclosure base.
9. Attach the enclosure base to the wall, using the screws delivered with the control panel.
10. Install the control panel mainboard module in its mountings inside the enclosure.
11. Install the battery.
12. Connect wires to the corresponding terminals of the control panel (see description of
connecting devices and power supply hereinunder).
13. Put the insert with zone descriptions into the slot intended for this purpose. The insert
template can be downloaded from the www.satel.eu website.
14. Replace the cover..
15. Secure the cover, using 4 screws.
16. Replace the screw protection caps.
17. If any installation or construction work is being carried out in the building, you should
protect the control panel against dust until such work is completed.
5.2 Connections
When running cables, remember to keep a suitable distance between low-voltage wires and
230 V AC power leads. Avoid running the signal wires in parallel to the 230 V AC power
leads in their immediate vicinity.
5.2.1 Zones
The CSP-108 and CSP-208 control panels have 8 zones, and the CSP-104 and CSP-204 –
4 zones. It is recommended that a screened cable be used to connect devices. For all zones,
a dedicated terminal for connecting the screen is situated next to the pair of terminals with
their polarity indicated.
The zone circuit should be terminated with a 5.6 kΩ resistor (the resistor can be screwed to
the terminals of the last device in the circuit). If the zone is not used, the resistor should be
screwed directly to the zone terminals.
Note: Do not connect the detectors and manual call points (MCPs) to the same zone.
Connecting the detectors
The total number of detectors connected to a zone must not exceed 32.
