SATEL Installation and Programming Manual 5
Fig. 2. Enclosure interior after removal of cover (by example of CSP-208): - control panel
mainboard module. – power supply. – metal insert for battery.
Fig. 3. Control panel mainboard module (by example of CSP-208): – RS-232 port.
- front panel. – location of slot for an insert with zone descriptions. – power supply
connector. – battery connector.
