ScanMeg SIM-P User Manual

ScanMegInc.     ModuleSIM‐P

UserManual  15   Version1.3

Display and membrane keypads

Thedisplayhas32alphanumericcharactersmountedintworowsof16characters.Whenthe
displayshowsinformation,thetwolinesareusedtodisplaythemessage.Whenthedisplayisused
toshowaparameter,thefirstlineinformsyouwhichoneoftheparametersisactuallydisplayed.In
thissituation,thesecondlineshowstheactualselectedvalueforthisspecificparameter.

Aselectedvaluehasanarrowoneachsideofthedisplay.Whenavalueisdisplayedwithoutthe
arrow,theseparametervaluesareavailable,butnotselectedatthistime.Toselectoneofthem
andmakethisvaluethenewactualsetupforaparameter,justmaintaintheenterkeyforone
second.Thearrowoneachsidewillappeartotellyouthenewselectedparameterisaccepted.

Atsomepoint,achoiceisnecessaryinordertocontinue.Whenthissituationoccurs,
theF1andF2
buttonarethechoicesavailabletoyou.Intotal,eightkeysarepresentonthemembranekeypads.
Thesekeysare:


Scrollup(previousparametermenu)
Displaysthepreviousparametermenuavailable.Fromthefirstmenu,itwilldisplaythe
lastone.

Scrolldown(nextparameter
menu)
Displaysthenextparametermenuavailable.Fromthelastmenu,itwilldisplaythefirst
one.

Next(parametervalue)
Showsthenextavailableparametervalueforeachspecificparametermenu

Previous(parametervalue)
Showsthepreviousavailableparametervalueforeachspecificparametermenu

Enter
Validationofacommand
orselectionofanewparametervalue

Cancel
Cancelstheactualcommandorsetupifseveralstepsarerequired

F1
Selection#1foracommand.Thesecondline(leftside)displaysthecorrespondingaction
linkwithF1

F2
Selection#2foracommand.Thesecondline(rightside)displays
thecorrespondingaction
linkwithF2
