ScanMegInc.     ModuleSIM‐P

UserManual  7   Version1.3

SIM-P module
The SIM‐P module is the controller for the Type P sensor heads.All parameter setups and
configurationsaremadewiththeSIM‐Pmodule.Theemitterandthereceiverareconnecteddirectly
tothetermi nalsonthisunit.Usingthedisplayandthemembranekeypad,onecanviewand
change
setups or parameters.All of these values are kept in a flash memory.At power up, all previous
configurations are in memory and the photocell continues to work as previously programmed.A
seriesofLEDsindicatethestateofeachcelllocated inthereceiver.Thisremoteviewingstateis
useful
fortroubleshooting theunitwhenthereceiver isnotmountedinaneasily  accessible location. The
SIM‐Plookslike:

Emitterorreceiver
Terminal

Emitterorreceiver
Terminal

LEDindicates
Receiverand
Emitterconnected

LEDindicatesan
objectisdetected

Alphanumeric
Display(2x16)

8buttons
membrane
Keypad

LEDarray
Indicatesstateof
eachreceivercell

PNP
Output

NPN
Output

Powerinput
(24volts)

Analogoutput
2x4‐20mA

LEDPowerindicator
InternalSupply
15and5Vdc

BargraphLED
Showinganalog
value

Bargraphshowing
DimensionorPosition

RS‐232
seriallink

RS‐422
seriallink


ScanMeg SIM-P Specifications

General

Brand	ScanMeg
Model	SIM-P
Category	Control Unit
Language	English
