ScanMegInc. ModuleSIM‐P
UserManual  13 Version1.3
Emitterhead
8. Power (Red)
The LED is located at the opposite end from the connector.
Theoneatthetopisthe powersupply,LEDstatus.Whenthe
SIM‐P module has power and the emitter is con nected, this
LEDis“on”.
9. Sync (Red)
TheLEDbelowthepowerLEDis“on”toindicatethe
presence
ofasynchronizationpulseatthe emitterlevel.IfthesyncLED
isnot“on”,detectionofanobjectisnotpossible.
