ScanMegInc. ModuleSIM‐P
UserManual  18 Version1.3
How to install or remove Sensor head with a bracket
Thesensorheadcanberemovedorinstalledonitsmountingbracketatanytime.Thecablecanbe
unpluggedatanytime.In thefollowingparagraph,wewillconnectandun‐connectthecableswhen
thesensorisfixedontoitsmountingbracket,butthisstepcanbedone
inanysequenceandnot
necessarilyintheordershowninthefollowingprocedure.
Toremoveasensorfromitsmountingbracket,followthesesteps:
Removetheconnectorbyrotatingtheshellcounterclockwisedirectionby120
o
(Picture1).
Unplugtheconnectorbypullingitdown(Picture2).
Grabonlythephotocell,withoutthebracket,andpushuptoreleasethebottomfromthe
bracket(Picture3).
Maintai n thepressureand pullthebottompartofthephotocellawayfromthebracket.
(Picture4).
Releasethepressureonthephotocellandremoveit(Picture5).

Picture1
Picture2
Picture3Picture4
Picture5
