ScanMegInc.     ModuleSIM‐P

UserManual  22   Version1.3

Parameters
FastPCSetup(Pre‐selectedconfiguration)
Onecansetupmanyparametersatthesametimebyusingthepre‐configure dsetupbuiltintothe
SIM‐Pmodule’smemory.Sevendiffere ntsetupsareavailable.Eachonemodifiessomeparameter
accordingtothefollowingtable:

Lookupthecorrespondingsectionifafurtherexplanationisneededon
thesedifferentparameters.
When it is done, you can now change any individual parameter s according to your needs.These
presetsetupscanhelpyoutorapidlyfinetuneyoursensorsaccordingtoyourapplicationasopposed
tosettingupeachparameterindividually.
Asymbol”‐‐‐“insidethetableindicates
nochangeforthisparameter.Theparameterstayswiththe
previousvaluebeforeapplyingapre‐selectedconfiguration.



Parameter value for Pre-selected configuration For Heads: P150, P225, P300, P450, P600
Parameter
Pre‐selectedconfiguration
Default Fast Average Accurate Standard Severe Extreme
Minimum detectable
dimension
Off Off Off Off 50mm/2.4in. 80mm/3.2in. 120mm/4.7in.
Maximum detectable
dimension
Off Off Off Off Off Off Off
Scan accuracy
Standard Coarse Standard Fine Standard Standard Standard
Cell cancellation
‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐
Debounce time
2ms Off Off Off 5ms 10ms 15ms
Latch time
Off Off Off Off Off Off Off
Output logic
Light ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐
Language selection
English ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐
Measuring unit
Imperial ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐
Emitter intensity
High High High Low High High High
Serial Output
‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐
Baud Rate
‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐
