Attribute Information
Power Supply 9-36 VDC
IP-class IP 21
Overload Protection Yes (still recommended to use a 3A fuse)
Current consumption <15 mA (idle)
200-900 mA during charging (depending on supply voltage)
Charging time 2 hours and 20 minutes
Cable length 1,8 m
Assembly 1/4” UNC (Suited for RAM-Mount Size B)
Ambient Temperature -20°C to +70°C ~ -4°F to +160°F
Charging temperature +5°C to +45°C ~ -41°F to +113°F
Dimensions 70 x 35,5 x 113 mm 2,75 x 1,4 x 4,45 in
Weight 70 g ~ 0.2 lbs.
5.6 Battery charger
The battery charger also works as a holder for the Rocket Flex. The charger can be assembled
on the machine with a 1/4” UNC screw, same as RAM-Mount Size B holders. While the Rocket
Flex is charging the blue LED is ashing. When charging is nished, the blue LED is lit. The
charger is delivered with a 1.8 meter cable with open wires.
IMPORTANT!
During charing, the ambient temperature needs to be between +5° and +45°C.
~ -41°F to +113°F
35,5mm (1,4 in)
70mm (2,75 in)
113mm (4,45 in)
15/33
