Schaerer Barista operating instructions
Introduction | Labelling of coffee machine parts
1
Bean hopper (under the cup storage)
2
Milk foam button
3
Milk button
4
Autosteam outlet
5
Left brewing group with portalter
6
Outlet
7
SteamJet (steam cup warmer)
8
Right brewing group with portalter
9
Cup grid
10
Powersteam outlet
11
Hot water outlet
12
Powersteam knob
13
Hot water buttons
14
Beverage buttons
15
Function key
16
Touch display
17
Cup storage
18
Cup lighting
19
On/off button
20
Left/right grind level adjustment
Ready for operation display
21
Barista eld
22
Menu eld (opens the main menu)
23
SteamJet eld (steam cup warmer)
24
Notication eld
25
Right brewing group display
(In the example, right brewing group beverage dispensing status display)
26
Left brewing group display
(In the example, readiness for use of left brewing group)
