Schindler 3100/3300/6300 J 43402603 / 01 112/269
Copyright © 2017 INVENTIO AG
Code Drive Subsystem Message
0401
DRIVE SAFETY CHAIN INTERRUPTED
Safety circuit opened unexpected (for example, during trip)
C1:Any safety device has tripped (safety circuit opened)
A1:Check reason for tripping and resolve problem
C2:Safety circuit wiring faulty or safety circuit contact(s) defective or bad
adjusted
A2:Check general wiring safety circuit contacts
0402
E_DRIVE_TRIP_TOO_LONG
The car hasn't reached the intended destination floor within the legal time limit
(typically 45 s). This mechanism protects the driving mechanics in case of a
blocked car. For example, at traction elevator, no damage of the ropes. For
example, at hydraulic elevator, no damage of hydraulic jack/valves.
C1:Car blocked or moving too slowly
A1:Check for object in shaft blocking the car.Check car for obstruction
(too much friction at guide rails).
C2:Drive blocked or turning too slowly
A2:Check if brake opens right.Check parameter nominal speed at drive.
C3:Shaft information signal(s) faulty
A3:Check shaft info wiring and it signals (PHS, KS/KS1,
KSE/KSE_U/KSE_D, ..)
0403
DRIVE CONTACTORS FEEDBACK
C1:One of the feedback inputs(1) did switch during traveling, or(2) did
not switch after starting, or(3) did not switch after stopping.
A1:Check: wiring. Check: for contactor fault or input fault in the circuit
associated with the input?
C2:Emergency stop?
0404
DRIVE DIRECTION ERROR
C1:Wrong travel direction
A1:Check: wiring. Check: why the drive doesn't generate sufficient
torque
C2:FA/ Open loop: Contactors feedback wrong
C3:Closed loop: tacho defective or motor not energized and car moves
slowly by unbalancing situation
C4:Drive doesn’t generate sufficient torque
0405
DRIVE SHAFT INFORMATION
A1:Check: CAN cable, Check: CAN wiring
