Schindler 3100/3300/6300 J 43402603 / 01 135/269
Copyright © 2017 INVENTIO AG
2071
TRIP LEARNING UPPER FLAG EDGE DIFFER
C1:The EC application sets an new upper flag edge height. The difference
between the last value and this one is bigger than accepted.
A1:Check rope slip, Check encoder, Redo learning trip (Warning: Do not
change load while performing a learning trip)
2072
TRIP LEARNING LOWER FLAG EDGE DIFFER
C1:The EC application sets an new lower flag edge height. The difference
between the last value and this one is bigger than accepted.
A1:Check rope slip, Check encoder, Redo learning trip (Warning: Do not
change load while performing a learning trip)
2073
TRIP LEARNING DOOR ENTRANCE SIDE DIFFER
C1:The EC application tried to set a door entrance side. The side was
already set, we allowed overwriting but the last value does not
correspond with the new one.
A1:Check rope slip, Check encoder, Redo learning trip (Warning: Do not
change load while performing a learning trip)
2074
TRIP POSITION NESTED MOVE
C1:A client requests a move in position mode, but the drive did not have
the time to acknowledge the last.
A1:Reset EC
2075
TRIP POSITION CORRECTION TOO BIG
The first limit for the correction of the car position (typically 30 mm) during a trip
has exceeded. Note that this warning is only applicable for closed loop drives.
The current running trip does not get interrupted.
C1:Insufficient traction
A1:Check for excessive rope slip
C2:Mechanical problem with motor tacho
A2:Check tacho on hoisting machine
C3:Excessive rope elongation during trip
A3:Check ropes (type and number of ropes)
C4:Problem with floor sensor (flag/photocell)
A4:Check correct installation/operation of floor sensors in hoistway
C5:Delayed transmission from floor sensor interface board (SDIC7x) to
the drive frequency converter (FC)
A5:Check communication on CAN bus (termination)
C6:Faulty input on the interface board (PCB) for the floor sensor
A6:Replace interface board (SDIC7x)
2076
TRIP LEARNING AVERAGE FLAG LENGTH EXCEEDED
C1:The calculation of the average flag length after the adjustment of the
FC parameter traction "PULLEY_DIAMETER" results in a value bigger
than the tolerated limit.
A1:Check shaft information. Check flags length. Check FC parameter
11.26 "Traction Pulley Diameter-DD", Redo learning trip
Code Trip Manager Message
