Schindler 3300 - Page 136

Schindler 3100/3300/6300 J 43402603 / 01 136/269
Copyright © 2017 INVENTIO AG
2077
TRIP LEARNING FLAG EDGE SEQUENCE
C1:During the learning trip the same edge is received twice in line. For
example, two times a rising edge with no falling edge in between.
A1:Check light barrier. Check SDIC7x board, Check CAN bus (cable,
termination, plugs, EMC)
2078
TRIP FINAL LEVEL NOT FOUND
The terminal floor indication (top or bottom floor) is faulty
C1:The distance between the signalization of the hoistway end and the
corresponding terminal floor (top respectively bottom floor) is out of
range
A1:Check position of terminal floor sensor (top or bottom floor, for
example, PHS), Check position of hoistway end sensor (for example,
KSEx)
C2:The signal indicating the hoistway end is faulty
A2:Check hoistway end sensors (for example, KSEx).Check general
wiring to this sensor.
C3:The signal indicating the terminal floor is faulty
A3:Check (terminal) floor sensor (for example, PHS).Check general
wiring to this sensor.
2079
TRIP PHSx SIGNAL PERSISTENTLY BRIDGED
During a trip the shaft information signal PHS and/or PHS1 do not change their
state as expected. They are permanently active (for example, bridged for test).
C1:PHS/PHS1 bridge for test still mounted
A1:Remove bridge. Perform a manual reset respectively perform the
persistent fatal error reset procedure to set the elevator back in
operation.
C2:Connection to PHS or PHS1 bad
A2:Check wiring to PHS/PHS1.Perform a manual reset respectively
perform the persistent fatal error reset procedure to set the elevator back
in operation.
C3:PHS or PHS1 sensor defect
A3:Replace corresponding sensor. Perform a manual reset respectively
perform the persistent fatal error reset procedure to set the elevator back
in operation.
2080
TRIP PHNR SIGNAL INCONSISTENT
After each landing of the car on a floor a consistency check of the shaft
information signals for releveling PHNR_U and PHNR_D gets performed. This
error occurs if both of the signals are inactive at this point of time.
C1:Sensor position of PHNR_U/PHNR_D wrong
A1:Check these sensors for misalignment
C2:The shaft information signals PHNR_U/PHNR_D are faulty
A2:Check sensors PHNR_U/PHNR_D for dirt or defect. Check general
wiring PHNR_U/PHNR_D.
2082 TRIP HOURS IN SERVICE MISMATCH
2083 TRIP HOURS IN SERVICE ENTERED MANUALLY
2084 TRIP COUNTER MISMATCH
2085 TRIP COUNTER ENTERED MANUALLY
Code Trip Manager Message
