Schindler 3100/3300/6300 J 43402603 / 01 137/269
Copyright © 2017 INVENTIO AG
*) So marked error descriptions are not released officially by R&D. If necessary, contact
a specialist or the Locarno hotline for more information.
2086
FC NON DETERMINABLE PERS AT STARTUP
A blind floor PHSB is at the end of shaft
2087
TRIP LEARNING BLIND FLOOR UNEXPECTED
A blind floor flag (PHSB) has been detected on a system where no blind floors
are expected
Code Hoistway Message
2101
SHAFT UNDEFINED
C1:Shaft is undefined yet.
A1:Do: Manually reset the system on microprocessor board
2102
SHAFT LEVEL MISSING
C1:The shaft information contains missing levels.
A1:check shaft info
2103
SHAFT NUMBER OF LEVELS VARY
C1:The total number of levels stored in the EEPROM differs from the
actually measured.
A1:Redo: learning trip
2104
SHAFT LEVEL OUTSIDE ARRAY LIMITS
C1:Too many floors. While setting up the RAM shaft image at the
application startup a level is addressed outside the array limits. [Level <0
or level > 15]
A1:Check: number of magnets/ flags. Redo: learning trip
2110
SHAFT IMAGE IN ERROR STATE
C1:The shaft image object is in error state due to an error at the
application startup.
A1:The system error handling automatically does a synchronization trip.
2111
SHAFT INVALID ROUGH POSITION
C1:This error can result from an invalid respectively incomplete
signaling of KSE indicator changes.
A1:See 2110.
2112
SHAFT INVALID SHAFT STAGE
C1:This error can result from an invalid respectively incomplete
signaling of PHS respectively KS indicator changes.
A1:See 2110.
2113
SHAFT INVALID CURRENT LEVEL
C1:This error can result from an invalid respectively incomplete
signaling of PHS respectively KS indicator changes.
A1:See 2110.
Code Trip Manager Message
