Schindler 3300 - Page 141

Schindler 3100/3300/6300 J 43402603 / 01 141/269
Copyright © 2017 INVENTIO AG
2162
SHAFT UPPER FLAG EDGE ALREADY SET
C1:While setting up the RAM shaft image at the application startup the
upper flag edge position of a level is about to be set multiple times.
A1:Check: rope slip. Check: encoder. Check: flag position. Redo:
learning trip
C2:Problems with shaft info circuit (PHS, light barrier, magnet switch)
C3:EMC disturbances
2163
SHAFT UPPER FLAG EDGE NOT SET
C1:While setting the RAM shaft image at the application startup, a
missing upper flag edge position is detected.
A1:Manually erase the shaft image file on the persistent data medium and
run the synchronization trip.
2164
SHAFT LOWER FLAG EDGE ALREADY SET
C1:While setting up the RAM shaft image at the application startup the
lower flag edge position of a level is about to be set multiple times.for
example, caused by arriving at the flag edge toggling many times.
A1:Redo: learning trip
C2:EMC disturbances
C3:Problems with shaft info circuit.(PHS, light barrier, magnet switch)
2165
SHAFT LOWER FLAG EDGE NOT SET
C1:While setting the RAM shaft image at the application startup a
missing lower flag edge position is detected.
A1:Redo: learning trip
C2:Problems with shaft info circuit (PHS, light barrier, magnet switch)
C3:EMC disturbances
2166
SHAFT INVALID DOOR ENTRANCE SIDE
C1:While setting up the RAM shaft image at the application startup an
invalid door entrance side is detected.
A1:Redo: learning trip
C2:See 2165
C3:See 2165
2166
SHAFT INVALID DOOR ENTRANCE SIDE
C1:While setting up the RAM shaft image at the application startup an
invalid door entrance side is detected.
A1:Redo: learning trip
C2:See 2165
C3:See 2165
2167
SHAFT DOOR ENTRANCE SIDE NOT SET
C1:While setting up the RAM shaft image at the application startup a
missing door entrance side is detected.
A1:Redo: learning trip
C2:Problems with shaft info circuit (PHS, PHUET, light barrier, magnet
switch)
C3:EMC disturbances
Code Hoistway Message
