Schindler 3100/3300/6300 J 43402603 / 01 142/269
Copyright © 2017 INVENTIO AG
2168
SHAFT DOOR ENTRANCE SIDE ALREADY SET
C1:While setting up the RAM shaft image at the application startup the
door entrance side of a level is about to be set multiple times.
A1:Redo: learning trip
C2:Problems with shaft info circuit (PHS, PHUET, light barrier, magnet
switch)
C3:EMC disturbances
2169
SHAFT INVALID LOWER FLAG EDGE
C1:While setting up the RAM shaft image at the application startup an
invalid lower flag edge position is detected.
A1:Redo: learning trip
C2:See 2165
C3:See 2165
2170
SHAFT INVALID UPPER FLAG EDGE
C1:While setting up the RAM shaft image at the application startup an
invalid upper flag edge position is detected.
A1:Redo: learning trip
C2:See 2165
C3:See 2165
Code FA Message
2200
to
2205
FA drive errors (2 speed systems) Not used with Schindler
3100/3300/6300
If one of these error occurs please contact hotline Locarno or a specialists.
Code Frequency Converter Alarming Message
2309
FC ALARM UNDERVOLTAGE
Under voltage at the drive inverter internal DC link detected
2315
FC ALARM MOTOR STALLED
C1:FC (Closed Loop) Motor stalled
A1:Check motor. Check electromechanical brake MGB
C2:The motor stall protection has tripped for example, electromechanical
brake (MGB) has not opened. Note: You can program if this condition
generates A15 or F15 or nothing.
Code Hoistway Message
