Schindler 3100/3300/6300 J 43402603 / 01 158/269
Copyright © 2017 INVENTIO AG
*) So marked error descriptions are not released officially by R&D. If necessary, contact
a specialist or the Locarno hotline for more information.
3591
SAFETY CIRCUIT TEST TAP SHAFT FAILURE
The controller detects that one of the following taps: ISKT3B, IRTS, I2KV,
IRTTV, ISKT4 fails to work
3596 SAFETY CIRCUIT RECOVERY SUCCESSFUL *)
3597 SAFETY CIRCUIT RECOVERY UNSUCCESSFUL *)
3598 SAFETY CIRCUIT RECOVERY DOOR SUCCESSFUL *)
3599 SAFETY CIRCUIT RECOVERY DOOR UNSUCCESSFUL *)
Code Communication Message
3601
BUS SCAN FAILED
At startup the controller checks if all bus nodes (for example, landing operating
panels) are communicating with the main controller. This error occurs if this
check fails. Note that this error does not occur if an additional node is
connected to the bus.
C1:Bad connection to any bus node (for example, landing operating
panel)
A1:Check generally bus wiring. Check bus connector on controller main
board and at all bus nodes.
C2:Bad bus power supply
A2:Check supply voltage on bus for instability
C3:EMC problems
A3:Check entire bus for interferences
3602
LOP COUNT FAILED
After configuration of the bus nodes (for example, landing operating panels) a
check of all possible node addresses is performed and the corresponding IO
function mapping get read. This error occurs if there is a communication
problem to any bus node during this phase.
C1:Bad connection to any bus node (for example, landing operating
panel)
A1:Check generally bus wiring. Check bus connector on controller main
board and at all bus nodes. Redo LOP count (CF00, LE00).
C2:Bad bus power supply
A2:Check supply voltage on bus for instability.Redo LOP count (CF00,
LE00).
C3:EMC problems
A3:Check entire bus for interferences. Redo LOP count (CF00, LE00).
Code Safety Chain Message (SIAP)
