Assembly of lock case parts
Schlage • L-Series service manual • 101
Assembly of lock case parts
Turn hub spring and transfer lever
Transfer Lever
Turn Hub Spring
Auxiliary Bar
Guide
Locking catch/retractor catch and locking link
Locking
Link
Locking Catch
