Trim options
Schlage • L-Series service manual • 103
Trim options
Cast or forged levers, standard lever designs
Standard levers are available in forged brass or bronze, and cast stainless steel. Levers are shown with rose trim A or B.
Also available with L or N escutcheon. See escutcheon options on pages 107-108.
01
2
¹¹⁄₁₆
"
2
¹⁄₁₆"
2
¹⁄₁₆
"
3⁷⁄₈
"
02
2¹³⁄₁₆"
1
¹³⁄₁₆"
1
¹³⁄₁₆
"
4³⁄₄"
03
4³⁄₄"
2¹³⁄₁₆"
2"
¹⁄₂
"
Dia.¹¹⁄₁₆"
05
2
⁷⁄₈
"
3³⁄₄
"2
⁹⁄₃₂"
2
⁹⁄₃₂
"
06
2
¹⁄₂
"
¹⁄₂
"
4⁵⁄₈
"2"
07
2
⁷⁄₈
"
4⁵⁄₈
"2
³⁄₈"
1
³¹⁄₃₂
"
12
3¹⁄₁₆"
max.
2"
2"
4⁵⁄₈
"
17
¹⁄₂"
3"
4³⁄₄"
2¹⁄₈"
2
¹⁵⁄₁₆"
18
2¹¹⁄₁₆"
2
¹⁄₃₂"
2
¹⁄₃₂
"
4⁷⁄₈
"
OME
³⁄₈"
2³⁄₁₀"
5¹⁄₁₆
"
3⁵⁄₁₆"
93 Bent extruded bar lever design
NOTE: The 93 lever design
is discontinued.
5"
3
¹⁄₈
"
2
⁹⁄₃₂"
⁷⁄₁₆" Dia.
¹¹⁄₁₆
"
Inside lever assembly Outside lever
assembly
NOTE: See Schlage Commercial Price Book for available finishes.
