L9000 Trim assemblies chart
Schlage • L-Series service manual • 49
P/N Description
L0170 L0172 L9010 LM9310 LM9325 L9040 LV9040 L9040/XL11-446** LV9040/XL11-446** L9044* LV9044 L9050 LM9350 LV9050 LMV9350 L9056 LV9056 L9060 LV9060 L9070 LM9370 LV9070 LMV9370 L9071 LM9371 LV9071 LMV9371 L9076 LV9076 L9077 LV9077 L9080 LM9380 LV9080 LMV9380 L9080EL LV9080EL L9080EU LV9080EU L9080EL-RX*** L9080EU-RX***
BB
Assembled lock case:
L283-173
Storeroom,
LV‡
•
L283-174
Electrically
locked, LV‡
•
L283-175
Electrically
unlocked, LV‡
•
L283-176 Entrance, LV‡
L283-177
Corridor,
classroom
security x
deadbolt, LV‡
L283-178
Hotel/Hotel x
indicator, LV‡
L283-180
Oce with
simultaneous
retraction, LV‡
•
L283-181
Privacy with
deadbolt, LV‡
L283-182 Institution, LV‡
L283-183
Institution
deadbolt, LV‡
L283-146
Institution
deadbolt‡
XL11-557 Prison‡
L283-139
Deadbolt with
fixed trim‡
XL11-741
Double
dummy with
active knob/
lever‡
L283-139
Deadbolt
retract x inside
knob/lever‡
L283-310
Classroom
security with
auxiliary latch
x deadbolt
L283-311
Classroom
security with
auxiliary latch
x deadbolt,
LV‡
L283-314
Passage/Exit x
multipoint
• •
L283-316
Oce, inner
entry x
multipoint
• • • •
L283-317
Oce, inner
entry x
multipoint, LV‡
• • • •
‡ Not sold separately as a part.
* Available with rose trim only.
** Available with knob x rose trim only.
*** Not available with N escutcheon.
